Send us the car model/ model year and the rear-view mirror housing pictures, and we will send you the correct integrated dashcam model.
| Model No | A19-1-1CH | Model No | A19-1-2CH |
|---|---|---|---|
|
Channel |
Front Cam only | Channel | Front and Rear Cam |
|
Processor |
NT96675 | Processor | NT96675 |
|
Screen |
/ | Screen | / |
| Image Sensor | IMX335 5M CMOS | Image Sensor | IMX307 2M CMOS |
|
Lens Material |
2G4P+IR waterproof | Lens Material | 2G4P+IR waterproof |
|
Aperture |
F1.4 | Aperture | F1.4 |
| Lens Angle | diagonal 143° |
Lens Angle |
diagonal 143° |
| Max Resolution | 2560*1600 | Max Resolution | 1920*1080 |
| Encoding Type | H.264 | Encoding Type | H.264 |
| Video Format | H.264encoding， TF format storage | Video Format | H.264encoding, TF format storage |
| Effective Pixel | 5 million pixel | Effective Pixel | 2 million pixel |
| Picture Format | JPEG | Picture Format | JPEG |
| Recording Mode | 1min/3mins/5mins/loop recording | Recording Mode | 1min/3mins/5mins/loop recording |
| Storage | TF card（Class 10 or above, max support 512G) | Storage | TF card（Class 10 or above, max support 512G) |
| GPS | Support, external GPS optional | GPS | Not Support |
| Wireless Connection | 802.11b/g/n/ac | Wireless Connection | 802.11b/g/n/ac |
| Collision Detection | Triaxial accelerometer | Collision Detection | Triaxial accelerometer |
| Horn | 8Ω1W | Horn | 8Ω1W |
| Parking Monitoring | Start recording 20s after collision | Parking Monitoring | Start recording 20s after collision |
| Start-up Time | About 10 Seconds | Start-up Time | About 10 Seconds |
| Working Voltage | DC12V | Working Voltage | DC12V |
| Working Currency | 250MA ±10MA | Working Currency | 250MA ±10MA |
| Operating Temperature | -20℃-65℃ | Operating Temperature | -20℃-65℃ |
| Storage Temperature | -30℃-85℃ | Storage Temperature | -30℃-85℃ |
| Front Cam Installation | Plug-and-Play or Hard-wiring Both Support | Front Cam Installation | Hard-wiring from the front cam |
